Explosion Proof Motor

YB3-250M-4 55kW 4 Pole Flameproof Asynchronous Motor 1480rpm 380V 660V Ex d IIC T4 IP55 for Coal Conveyor

All Category

PMDC Motor

Mrs. Anny Song

motorexport@bimo-idea.com

0086-18802094629

Contact Now

YB3-250M-4 55kW 4 Pole Flameproof Asynchronous Motor 1480rpm 380V 660V Ex d IIC T4 IP55 for Coal Conveyor

Brand Name:	BM
Model Number:	YB3-250M-4
MOQ:	1 Piece
Price:	USD 1620 - 2050 / Piece
Packaging Details:	Plywood case with moisture proof film and shock proof foam, export standard packing
Payment Terms:	T/T,L/C at sight,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ATEX, CE, ISO 9001:2015, CNEx

Frame Size:

Rated Power:

55 KW / 75 HP

Poles:

Rated Speed:

1480 R/min

Rated Voltage:

380 V / 660 V

Rated Frequency:

50 Hz

Rated Current:

102 A At 380 V

Efficiency:

93.5 % (IE3 Level)

Power Factor:

Insulation Class:

Class F (155 C)

Temperature Rise:

Class B (80 K)

Protection Degree:

Cooling Method:

IC411 Totally Enclosed Fan Cooled

Duty:

S1 Continuous

Mounting Type:

IM B3 Foot Mounted

Explosion Protection:

Ex D IIC T4 Gb

Ambient Temperature:

-20 C To +40 C

Bearing (DE / NDE):

6314 C3 / 6314 C3

Weight:

472 Kg

Supply Ability:

900 Pieces per Month

Highlight:

55kW flameproof asynchronous motor

4 pole 1480rpm explosion proof motor

Ex d IIC T4 IP55 conveyor motor

Product Description

YB3-250M-4 55 kW 4 Pole Flameproof Asynchronous Motor

The BM YB3-250M-4 delivers 55 kW at 4 pole in a compact 250M cast iron frame, which makes it the usual choice where a 75 kW motor would not fit on an existing conveyor or pump base. The Ex d IIC T4 Gb flameproof enclosure and IP55 sealing allow continuous duty in coal preparation plants, fuel depots and chemical workshops classified as Zone 1 or Zone 2.

Key Features

55 kW, 4 pole, 1480 r/min, S1 continuous duty for conveyor and pump loads
Compact 250M frame keeps the IEC footprint of the previous 55 kW unit
Ex d IIC T4 Gb flameproof enclosure for gas groups IIA, IIB and IIC
IE3 level efficiency (93.5 %) meets EU Ecodesign and cuts running cost
IP55 cast iron frame with IC411 fan cooling for dusty coal and cement areas
Class F insulation with Class B temperature rise for long winding life
Dual voltage 380 V / 660 V winding supports Y-Δ starting
PTC thermistor, space heater and B5 flange available on request

Technical Parameters

Parameter	Specification
Frame Size	250M
Rated Power	55 kW / 75 HP
Number of Poles	4
Rated Speed	1480 r/min
Rated Frequency	50 Hz
Rated Voltage	380 V / 660 V
Rated Current	102 A (380 V)
Efficiency	93.5 % (IE3 level)
Power Factor	0.87
Insulation Class	Class F (155 °C)
Temperature Rise	Class B (80 K)
Protection Degree	IP55
Cooling Method	IC411, totally enclosed fan cooled
Duty / Connection	S1 continuous / Y-Δ start
Explosion Protection	Ex d IIC T4 Gb
Ambient Temperature	-20 °C to +40 °C
Altitude	Up to 1000 m
Bearing (DE / NDE)	6314 C3 / 6314 C3
Terminal Box	IP55, 2 cable entries, 6 terminals
Approximate Weight	472 kg

YB3 Series 4 Pole Quick Reference

Frame Size	Poles	Rated Power	Speed (r/min)	Current at 380 V (A)
YB3-250M-4	4	55 kW	1480	102
YB3-280S-4	4	75 kW	1480	139
YB3-280M-4	4	90 kW	1480	164
YB3-315S-4	4	110 kW	1485	199
YB3-315M-4	4	132 kW	1485	238

Typical Applications

Oil and gas pumping stations, petrochemical process lines, coal mining conveyors, cement and steel plants, grain processing, chemical and pharmaceutical workshops and other Zone 1 / Zone 2 hazardous areas that require certified explosion proof drive equipment.

FAQ

Q: Can you supply the complete 4 pole power range?
A: Yes. Our YB3 flameproof range covers 55 kW, 75 kW, 90 kW, 110 kW and 132 kW at 4 pole from stock or short production runs.

Q: Are the mounting dimensions interchangeable with old YB2 or YBX motors?
A: Yes. IEC frame dimensions follow the standard Y series footprint, so the motor usually replaces an ageing unit without base modification.

Q: What certificates come with the motor?
A: ATEX 2014/34/EU certificate copy, CNEx certificate, routine test report and outline drawing are supplied with every shipment.

Q: What is your lead time?
A: 15 to 25 working days after deposit, depending on power rating and voltage configuration.

Contact Us

Send us the required power, voltage and mounting type. Our engineers confirm the frame selection, price and delivery schedule within 24 hours.
