380V 50Hz 22KW Three Phase Induction Motor 30HP Cast Iron IE3 Electric Motor

All Category

PMDC Motor

Mrs. Anny Song

motorexport@bimo-idea.com

0086-18802094629

Contact Now

380V 50Hz 22KW Three Phase Induction Motor 30HP Cast Iron IE3 Electric Motor

Brand Name:	BM
Model Number:	Y2-180M-2
MOQ:	10 Pieces
Price:	USD 180-320 / Piece
Packaging Details:	Shock-proof foam insert, export-grade corrugated carton, fumigation-free plywood pallet
Payment Terms:	T/T, L/C, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

Zhejiang, China

Certification:

CE, ISO 9001

Rated Power:

22 KW (30 HP)

Rated Voltage:

380 V

Frequency:

50 Hz

Phase:

Three Phase

Poles:

2 Pole

Rated Speed:

2940 R/min

Efficiency Class:

Protection Degree:

Insulation Class:

Class F

Mounting Type:

B3 / B5 / B35

Frame Material:

Cast Iron

Warranty:

12 Months

Supply Ability:

5000 Pieces per Month

Highlight:

380V 50Hz 22KW Three Phase Motor

30HP IE3 Induction Motor

Cast Iron IP55 Electric Motor

Product Description

The Y2-180M-2 380V 50Hz 22KW three phase induction motor delivers a rated output of 22 kilowatts, equivalent to 30 horsepower, and is engineered for heavy continuous duty in the European industrial market. Built on a rigid cast iron frame with a fully enclosed fan-cooled (TEFC) construction and IE3 premium efficiency winding, this 30HP electric motor combines high starting torque with remarkably low noise and vibration. As a true workhorse, it converts electrical energy into mechanical drive power with minimal losses, making it a dependable and cost-effective choice for pumps, fans, compressors, conveyors, and machine tools. Every unit ships with CE marking and complete technical documentation, ready for the Italian and wider EU B2B market.

Key Features

22KW / 30HP Rated Output: A robust 22 kilowatt rating (30 horsepower) at 380V 50Hz, sized for demanding continuous industrial loads.
IE3 Premium Efficiency: The IE3 efficiency class reduces energy consumption and operating cost while satisfying current European ecodesign expectations for electric motors.
100% Copper Winding: Precision-wound, full copper stator windings deliver high thermal conductivity, low resistance, and stable performance over a long service life.
Cast Iron Frame with IP55 Protection: The rugged cast iron housing and IP55 enclosure resist dust, moisture, and mechanical shock in harsh workshop and outdoor environments.
Class F Insulation: Class F insulation (155 degrees C) with a designed temperature rise provides a reliable thermal safety margin and extends motor durability.
CE Certified for the EU Market: Compliance with CE requirements ensures smooth import into Italy and across the European Union.
Flexible B3 / B5 / B35 Mounting: Multiple mounting configurations allow straightforward replacement and installation in existing drive trains.

Technical Specifications

Parameter	Specification
Model	Y2-180M-2
Rated Power	22 KW (30 HP)
Rated Voltage	380 V
Frequency	50 Hz
Phase	Three Phase
Poles	2 Pole
Rated Speed	2940 r/min
Rated Current	41 A
Efficiency Class	IE3
Power Factor	0.90
Protection Degree	IP55
Insulation Class	Class F
Cooling Method	IC411 (TEFC)
Mounting Type	B3 / B5 / B35
Frame Material	Cast Iron
Working System	S1 Continuous
Ambient Temperature	-15 to +40 C
Net Weight	165 kg

Applications

This 380V 50Hz 22KW three phase induction motor is designed as a general-purpose industrial drive and performs reliably across a broad range of equipment. It is widely specified for centrifugal and positive displacement pumps, cooling and ventilation fans, screw and piston air compressors, belt and screw conveyors, mixers, and metal-cutting or woodworking machine tools. For Italian and EU industrial buyers, the IE3 premium efficiency class helps meet energy-saving targets while lowering long-term running costs, and the robust cast iron construction suits factories, water treatment plants, agricultural processing lines, and food production facilities. The standard B3 foot-mount, together with optional B5 flange and B35 face-foot variants, simplifies integration into new machines or replacement of existing drives.

Packaging & Quality Assurance

Each motor is protected by a shock-absorbing foam insert and sealed in an export-grade corrugated carton, then placed on fumigation-free plywood pallets for safe sea freight to Italy and other European destinations. Every unit undergoes a strict quality inspection covering winding resistance, insulation, no-load current, vibration, and rotational balance before shipment, and is backed by a 12-month warranty. CE marking and full technical documentation are supplied with every order. For volume buyers, OEM and ODM service, customized nameplates, and long-term supply agreements are available on request. Contact our export team for the latest FOB or CIF quotation to your Italian port, and we will recommend the most economical shipping schedule for your order.
