High Efficiency Brushed DC Motor 90V 750W 1750Rmp DC Motors 1HP

Brand Name:	BM
Model Number:	PMDC
MOQ:	10 pcs
Price:	Negotiation
Packaging Details:	Cartons/pallet
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Name:

90V DC Motor

Speed(RPM):

1750rpm

Efficiency:

Power:

Rated Voltage:

Frame:

Supply Ability:

10000pcs per month

Product Description

High Efficiency Brushed DC Motor 90V 750W 1750Rmp DC Motors 1HP

1, This 1/3HP 1750RPM TEFC Permanent Magnet DC Motor is a multi-voltage PMDC brushed motor offered in 12V, 24V and 90VDC options.

2, Adopting Totally Enclosed Fan Cooled TEFC design, this 0.33HP dc motor features IP54 dust & splash resistance, Class F insulation and stable constant torque at 1750 full load RPM.

3, Built with high energy permanent magnet and replaceable carbon brushes, it supports S1 continuous running, widely used in battery-powered machinery, small conveyors, DC pumps and light industrial equipment. Standard NEMA frame foot & C-face mounting for direct replacement.

Power(HP)	Speed(RPM)	Arm Volt	NEMA FRAME	ENCL.	Curret(Amp.)	Torque(In.Ibs)	App.Weights(Ibs)
1/4	1750	12	56C	TEFC	21.0	9	21
1/4	1750	24	56C	TEFC	10.5	9	21
1/3	1750	12	56C	TEFC	27.0	12	23
1/3	1750	24	56C	TEFC	13.5	12	23
1/2	1750	12	56C	TEFC	39.0	18	25
1/2	1750	24	56C	TEFC	20.0	18	25
3/4	1750	12	56C	TEFC	63.6	27	30
3/4	1750	24	56C	TEFC	31.8	27	30
3/4	3600	12	56C	TEFC	63.6	13	23
3/4	3600	24	56C	TEFC	31.8	13	23
1	1750	12	56C	TEFC	80.0	36	32
1	1750	24	56C	TEFC	40.0	36	32
1	3600	12	56C	TEFC	80.0	17.6	25
1	3600	24	56C	TEFC	40.0	17.6	25
1.5	1750	24	56C	TEFC	60.0	54.3	43
1.5	3600	24	56C	TEFC	60.0	26.4	30

High Efficiency Brushed DC Motor 90V 750W 1750Rmp DC Motors 1HP

Q: Are you Factory or Trading Company?
A: We are Factory. That has been focusing on motors and accessories for more than 20 years.

Q: What is your warranty?
A: Our warranty is One Year. Any parts damaged within warranty. We will provide new one for free and supply the solution.

Q: What kind of motor can you supply?
A: Single Phase Motor, Three Phase Motor, NEMA standard motor, Explosion Proof Motor etc.

Q: Do you offer OEM Service?
A: Yes. We offer OEM/ODM service.

Q: What is your lead Time?
A: Usually 10 days. Precise Time depend on Qty.
