NEMA 56C Frame 3/4HP (0.75HP) 24V DC Permanent Magnet Brushed PMDC Motor, 1750RPM / 1800RPM Variable Speed Brush DC Motor for Industrial Conveyor AGV

Brand Name:	BM
Model Number:	PMDC
MOQ:	10 pcs
Price:	Negotiation
Packaging Details:	Cartons/pallet
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Name:

Permannet DC Motor

Speed(RPM):

1750rpm

Construction:

Permanent Magnet

Power:

3/4HP

Voltage:

Frame:

Supply Ability:

10000pcs per month

Highlight:

NEMA 56C Frame PMDC motor

24V DC brushed motor 1750RPM

industrial conveyor AGV DC motor

Product Description

NEMA 56C Frame 3/4HP (0.75HP) 24V DC Permanent Magnet Brushed PMDC Motor, 1750RPM / 1800RPM Variable Speed Brush DC Motor for Industrial Conveyor AGV

1,This NEMA 56C 3/4HP 24V DC Permanent Magnet Brushed Motor is a high-performance PMDC brushed motor built to NEMA MG1 56C standard mounting dimensions.

2,Rated 0.75HP, 24VDC, 1750/1800 full-load RPM, it delivers constant high torque across wide speed range with reliable carbon brush commutation.

3,Adopt high-energy permanent magnet, Class F insulation, IP54 protection, TEFC/TENV enclosure optional. Standard NEMA 56C C-face flange & removable foot base for direct replacement of all 56C frame motors, widely used in battery-powered mobile equipment, conveyors, packaging machinery and light industrial automation.

Power(HP)	Speed(RPM)	Arm Volt	NEMA FRAME	ENCL.	Curret(Amp.)	Torque(In.Ibs)	App.Weights(Ibs)
1/4	1750	12	56C	TEFC	21.0	9	21
1/4	1750	24	56C	TEFC	10.5	9	21
1/3	1750	12	56C	TEFC	27.0	12	23
1/3	1750	24	56C	TEFC	13.5	12	23
1/2	1750	12	56C	TEFC	39.0	18	25
1/2	1750	24	56C	TEFC	20.0	18	25
3/4	1750	12	56C	TEFC	63.6	27	30
3/4	1750	24	56C	TEFC	31.8	27	30
3/4	3600	12	56C	TEFC	63.6	13	23
3/4	3600	24	56C	TEFC	31.8	13	23
1	1750	12	56C	TEFC	80.0	36	32
1	1750	24	56C	TEFC	40.0	36	32
1	3600	12	56C	TEFC	80.0	17.6	25
1	3600	24	56C	TEFC	40.0	17.6	25
1.5	1750	24	56C	TEFC	60.0	54.3	43
1.5	3600	24	56C	TEFC	60.0	26.4	30

NEMA 56C Frame 3/4HP (0.75HP) 24V DC Permanent Magnet Brushed PMDC Motor, 1750RPM / 1800RPM Variable Speed Brush DC Motor for Industrial Conveyor AGV 0

NEMA 56C Frame 3/4HP (0.75HP) 24V DC Permanent Magnet Brushed PMDC Motor, 1750RPM / 1800RPM Variable Speed Brush DC Motor for Industrial Conveyor AGV 2

NEMA 56C Frame 3/4HP (0.75HP) 24V DC Permanent Magnet Brushed PMDC Motor, 1750RPM / 1800RPM Variable Speed Brush DC Motor for Industrial Conveyor AGV 3

FAQ

Q: Are you Factory or Trading Company?
A: We are Factory. That has been focusing on motors and accessories for more than 20 years.

Q: What is your warranty?
A: Our warranty is One Year. Any parts damaged within warranty. We will provide new one for free and supply the solution.

Q: What kind of motor can you supply?
A: Single Phase Motor, Three Phase Motor, NEMA standard motor, Explosion Proof Motor etc.

Q: Do you offer OEM Service?
A: Yes. We offer OEM/ODM service.

Q: What is your lead Time?
A: Usually 10 days. Precise Time depend on Qty.
