YL90L-4 1.5KW 2HP Two-value Capacitor Single Phase Induction Motor Electric Asynchronous AC Motors CE Cast Aluminium 380v 400v 440v

Brand Name:	BM
Model Number:	YL90L-4
MOQ:	10PCS
Price:	USD35-USD120
Packaging Details:	Cartons/Pallets
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Name:

Cast Aluminium Motor

Protect Feature:

Frequency:

Efficiency:

Speed:

1500rpm

Power:

1.5KW

Supply Ability:

10000pcs per month

Highlight:

1.5KW single phase induction motor

2HP asynchronous AC motor

CE cast aluminium electric motor

Product Description

YL 90L-4 1.5KW 2HP Two Value Capacitor Single Phase Induction Motor Electric Asynchronous AC Motors CE Cast Iron 380v 400v

1, YL 90L-4 Motor is a dual-capacitor single-phase induction motor, widely used for 220V domestic & small industrial equipment, drip-proof foot mounted design.

2, Application:Perfect for air compressors, water pumps, fans, small lathes and general household & small processing machinery.

Main Specifications

Model: YL90L-4
Power: 1.5kW (2HP)
Voltage: 220V 50Hz
4 Pole, rated speed: approx 1420RPM
Protection: IP44 drip-proof, Class B insulation, S1 continuous duty

Franme reference and size	Rated power	Full load sreed in revolutions per minute	Full load current at rated voltage	Exciter Voltage	Efficiency	Power factor	Direct on ine starting torque ratio	Direct on linepull out torque ratio	Diect on line starting current ratio	Mean sound pressure level@1mon noload	Start Capacitor	Running Capacitor	Weight
Type	Output (KW)	Speed (r/min)	Amps (A)	Voltage (V)	EFF. (%)	P.F. Cos	LRT RLT	BDT RLT	LRA RLA	Noise LwdB(A)	(uf/v)	(uf/v)	Weight (kg)
YL711-2	0.37	2800	2.7	220	67	0.92	1.8	1.6	5.5	72	50/250	8/450	10
YL712-2	0.55	2800	3.9	220	70	0.92	1.8	1.6	5.5	72	100/250	15/450	11
YL711-4	0.25	1400	2.0	220	62	0.92	1,7	1.6	5.0	67	75/250	15/450	9
YL712-4	0.37	1400	2.8	220	65	0.92	1.7	1.6	5.0	67	75/250	15/450	10
YL801-2	0.75	2800	4.9	220	73	0.95	1.8	1.6	5.5	75	100/250	25/450	14
YL802-2	1.1	2800	7.0	220	75	0.95	1.8	1.6	5.5	75	100/250	30/450	15
YL801-4	0.55	1400	3.95	220	69	0.92	1.7	1.6	5.0	70	100/250	15/450	13
YL802-4	0.75	1400	5.05	220	71	0.95	1.7	1.6	5.0	70	100/250	25/450	14
YL90L1-2	1.5	2800	9.4	220	76	0.95	1.8	1.6	5.5	78	200/250	40/450	22
YL90L-2	2.2	2800	13.7	220	77	0.95	1.7	1.6	5.5	78	300/250	50/450	24
YL90L1-4	1.1	1400	7.3	220	72	0,95	1.7	1.6	5.0	73	150/250	30/450	21
YL90L-4	1.5	1400	9.7	220	74	0.95	1.7	1.6	5.0	73	200/250	40/450	23
YL100L-2	3	2800	18.2	220	79	0.95	1.7	1.6	6.0	83	350/250	55/450	24
YL100L1-4	2,2	1400	13,9	220	76	0.95	1,7	1.6	5.0	78	300/250	50/450	32
YL100L2-4	3	1400	18,4	220	78	0.95	1.7	1.6	5.0	78	350/250	55/450	33
YL112M-2	3,7	2800	22,1	220	80	0.95	1,7	1,6	6.0	83	350/250	60/450	46
YL112M-4	3.7	1400	22.4	220	79	0.95	1.7	1.6	5.5	83	350/250	60/450	44

YL90L-4 1.5KW 2HP Two-value Capacitor Single Phase Induction Motor Electric Asynchronous AC Motors CE Cast Aluminium 380v 400v 440v 0

YL90L-4 1.5KW 2HP Two-value Capacitor Single Phase Induction Motor Electric Asynchronous AC Motors CE Cast Aluminium 380v 400v 440v 1

FAQ

Q: Are you Factory or Trading Company?
A: We are Factory. That has been focusing on motors and accessories for more than 20 years.

Q: What is your warranty?
A: Our warranty is One Year. Any parts damaged within warranty. We will provide new one for free and supply the solution.

Q: What kind of motor can you supply?
A: Single Phase Motor, Three Phase Motor, NEMA standard motor, Explosion Proof Motor etc.

Q: Do you offer OEM Service?
A: Yes. We offer OEM/ODM service.

Q: What is your lead Time?
A: Usually 10 days. Precise Time depend on Qty.
